Micro-film electrostatic oiler applied in blankplate/aluminum foil/GL
Click to see big pic
Product Name:
Micro-film electrostatic oiler applied in blankplate/aluminum foil/GL
Sort:
Aluminum Ingot
Company:
Suzhou TRIOA E and M Equipment Co.; Ltd..
Location:
Contact Person:
Jimmy Hsu
Post Time:
2024/12/20
Free Member
Suzhou TRIOA E and M Equipment Co.; Ltd.
Tel:
0512-13912680768
Fax:
Add:
NO.29,HESHUN RD, SIP
Post Code::
E-mail:
jimmylg@126.com
Details
Low coating film weight is up to 2mg/m2 per side
V.E.S.O Coating weight: 2-12.5mg/m2 per side
H.E.S.O Coating weight:20-2500mg/m2 per side.
How it work?
The nozzle system educts oil from the reservoirs, atomizing it into micron sized particles in the fog chamber. Any large droplets impinge on and flow down the sides of the chamber, returning to the reservoir. A constant air pressure to the nozzles produces oil mist at a fixed rate, filling the chambers with a uniform oil fog. Approximately 100 times more oil mist is produced than is required to satisfy the maximum operating conditions.
Controlled airflow enters the fog chambers from the air plenums, moving the oil mist past baffles which help remove any larger droplets. The oil mist then moves into the Electrostatic Charging Section where a corona discharge field from the ionizing wires charges the oil particles negatively. After the mist passes through the ionizers, the negatively charged repelling plates force the charged mist particles toward the surfaces of the moving strip. Since the strip is at ground potential, the charged mist particles are also attracted toward the strip.
Other biz of this company
Welding wire electrostatic oiler
DOS oil Electrostatic Oiler
