Aluminium foil container production line CTJF-45T-China Aluminium Network

Product Name:Aluminium foil container production line CTJF-45T
Sort:Others
Company:Foshan Choctaek Machinery Mould Factory.
Location: China
Contact Person:Alice Chen
Post Time:2025/3/9

Free Member

Foshan Choctaek Machinery Mould Factory

Tel:86-757-85519885
Fax:86-757-85529852
Add:1#,Kanxia Industrial Area, Zhongbian Shengtang Beier Village,Dali town,Nanhai district,Foshan city,GD.China
Post Code::528231
E-mail:ctac558@hotmail.com

Details

Aluminum foil container production line CTJF-45T has been developed from production line CTJF-40T to produce aluminium food containers,dishes and trays. The working speed of production line CTJF-45T is 40-70 pcs/min (with one cavity mould), and its speed depens on container's size and complexity. The press of this production line is equipped with a higher closed height and a longer stroke length, so it can match a larger range of mould size than 40T Aluminium foil container prodcution lines is composed of the followings: 1. Decoiler (with an auto-lubricator) 2. Electrical control panel 3. Air output control equipment 4. 45T press 5. Mould 6. Conveyor 7. Collection desk Main Features of production lines: (1) Those production line can work automatically. Worker control and regulate this production line through electric control equipment. (2) The width of decoiler is about 500mm. (3) The feeding system control feeding length and stepping by computer, which assure a high-precision steps. (4) We can design and manufacture different machines on request. There is some difference in machine's outer-appearance. (5) The press may be equipped with single cavity or multi-cavity moulds for wrinkle-wall or smooth-wall container production. The working flow of production line: Aluminium foil roll---decoiler---air output control equipment--- press---mould---conveyor--- collection desk---packing
