Detail Information
Alloy: 1100/3003/3105/3005/5052
Specification: AS REQUIREMENTS
Delivery time : about 25 days
place of origin: TT and LC
place of origin: China
Standards: ASTM B209
General Information
It is widely used in decoration building industries such as Aluminum-plastic composite panel, Wall board outside, Ceiling board and Curtain wall. PET coating is becoming popular, and its property and price is in the middle of PVDF and Acrylic Acid coating. More users will use PET coating instead of Acrylic Acid coating. The flexibility of polyester is special in coating materials, it can be coated on its surface.
Detailed Product Description
Specifications:
01) Alloy: 1100,1200,1050,1060,3004, 3003,3005,3105,,8011...
02) Aluminum thickness: 0.06mm~4.0mm
03) Aluminum width: 100mm –3000mm
04) Coil's standard diameter: 1100mm
05) Coil's standard weight: 2000kgs
06) Coating finish: PVDF,POLYESTER, NANO,BRUSHED
07) Gloss:10-90%(EN ISO-2813:1994)
08) Total coating thickness:
PVDF coating: more than 25 micron
Polyester coating: more than 18micron (EN ISO-2360:1995)
09) Coating hardness (pencil hardness) more than 2H
10) Adhesion: 5B (EN ISO-2409:1994)
11) Impact resistance: No cracking and peeling (A.S.T.M D2794-1993)
12) Flexibility (T-bend): 0T- 2T
13) MEK resistance: more than 100
14) Bottom side aluminum sheet is coated with protective polyester material, thickness more than 6 micron
