Detail Information
SPECIFICATION UNIT Z3032 x 9/10
Max. drilling diameter mm casting32/steel casting27
Distance between spindle centerline and column generatrix mm 360~950 360-1050
Distance spindle nose and working surface of base plate mm 260-1050
Spindle travel mm 120
Range of spindle speeds r.p.m (6)108-1000
Spindle Number of feeds mm/r 3 level
Overall dimensions((L*W*H) mm 1350*700*1880
1500*705*2020
Main motor power kw 1.5/2.2
N.W/G.W kg 900/960
