Place of Origin: |
Zhejiang, China (Mainland)
|
Brand Name: |
Jinding
|
Model Number: |
8011
|
Grade: |
8000 3000
|
Thickness: |
0.15mm to 0.6mm
|
Width: |
49mm to 200mm
|
Application: |
water pipe
|
Surface Treatment: |
Embossed
|
Hardness: |
H0
|
Alloy Or Not: |
Is Alloy
|
Al (Min): |
97.52%
|
Yield (≥ MPa): |
115~125
|
Temper: |
O - H112
|
Ultimate Strength (≥ MPa): |
100-120
|
Elongation (≥ %): |
20%
|
material: |
aluminum
|
Packaging Details: | 1, seaworthy packing with wooden cases/plates for long distance transportation. 2, around 20tons per 20ft container. |
Delivery Detail: | 20-35 days |
1.high quality and the best service.
2.short delivery time.
3.flat surface with no oxidation, whole.
4.neat clean cutting
Dimension(MM) | 0.20*49*C; 0.23*61.7*C 0.28*77*C; 0.35*99*C | Alloy and Temper | 8011 0 | Product | aluminum coil/strip | ||||||
Techuique Standard | YS/T 434-2000 | ||||||||||
Chemical Composition(%) | |||||||||||
Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Other | Al | ||
≥ | |||||||||||
0.50~0.9 | 0.6~1.0 | 0.1 | 0.2 | 0.05 | 0.05 | 0.1 | 0.08 | - | remainder | ||
Notice: Aluminum foil not contains Pb,As and other Virose elements. | |||||||||||
Mechanical Property | |||||||||||
Temper | THICKNESS | Strength(Mpa) | Elongation(%) | ||||||||
0 | 0.20mm; 0.23mm; | 100~120 | 20% | ||||||||
0.28mm; 0.35mm |
