Detail Information
Application:
They are applied to non-touched cutting and drilling of metal or non-metallic plates, pipes.Especially designed for cutting and drilling stainless steel, iron, silicon, ceramic, diamond and other materials.
Also Widely used in machine tools, transportation machinery, metallurgical machinery, electronics, electrical appliances, electrical manufacturing, auto manufacturing, telecommunications, broadcasting and information industry, aerospace ,petroleum, chemical , stone, plastic,rubber and other industries
Technical data
Model EFE-LPC-200 EFE-LPC-300 EFE-LPC-400 EFE-LPC-500
Wavelength 1064nm
Output power 200W 300W 400W 500W
Beam divergence angle ≤3mrad
Stability of energy ≤±1.5%
Pulse width 0.2ms-20ms
Pulse frequency 1-300Hz
Max Cutting speed 1.5m/min
Max cutting thickness 2/3/5mm
Cutting linear width 0.1-0.8mm
Repetition accuracy ±0.01mm
Max Position speed 3m/min
Max drilling depth 12mm (Depending on different materials)
Workbench stoke(XYZ) 300×300×150mm(dimension optional )
Continuous working hours 24h
