Detail Information
Pharmaceutical Paper/PE Flexible(Lamination Type)
Technical Data Sheet
Paper/PE film
Paper 80g
PE film 20my
Total thickness tolerance: + or -10%
Max width:1050mm
Appearance
Rolling up tightly and evenly, neat sides, no perforation、peculiar smell、adhesion and foreign matters,no obvious bubbles、wrinkles、dirt and other defects. not have any obvious variation or loose for inner core, no serious broken and concave outside presented, the joint per roll is no more than 2.sealing parts of the composited bags should be smooth and no virtual closure.
Technical details
Water Vapor Transmission Rate ≤15g/ g/m2•24h
Oxygen Transmission ≤4000cm3/m2•24h•0.1Mpa
Peel strength (Longitudinal/Transversal) ≤1.0N/15mm
Heat Seal Strength ≤ 7.0N/15mm
Reels
Cores: 76mm ,152mm
Reel width: 70-1000mm
Microbial Limit
Bacteria Number ≤15/100cm2
Number of mould and saccharomycete ≤15/100cm2
Number of Escherichia Coli not allowed
Chemical Performance
Less than 5mg/m2
No Benzene Solvent Residue
Non volatile substance ≤30mg
Easy Oxide ≤1.5ml (Titration)
Heavy Metal ≤1ppm
Toxicity Non toxic
Test Standard
SCHL20120017 (YBB00132002 as reference)
