Detail Information
The structure:
Print primer polyurathene base lacquer 1.5gr/m2+/- 0.5gr
Aluminum 20µ Hard 54.0gr/m2+/-8%
Heat-seal lacquer (code by-201)
Acrylic vinyl coating 7gr/m2+/-1.5gr
Total weight 62.5gr/m2+/-8% (total thickness 26µ +/-8%)
Technical details
tensile strength: More than 150n/mm2
Elongation: 1%-5%
Sealing temperature 180-240 degree
Bond strength more than 7.0n/15mm to PVC
At 160 degree, 1 sec, 4kp/cm2
Pores none
Reels cores( paper or steel) 76mm
Max reel width: 800mm
